Approval no.: E8 67R01 3018/16
Multivalve type: internal toroidal 30 degrees standard (d 6 mm)
Model: ELPIGAZ AT02 SPRINT
Height [H]: 220-225 mm
Application to internal toroidal tanks. 30 degrees with MVA flange for 6 screws:
- height [H]: 220-225 mm
- diameter [D]: 565-720 mm
Gas input (refueling): M12x1.0 mm, cable - d 8 mm
Gas outlet (to the reducer): M10x1.0 mm, cable - d 6 mm
Assembly: without gas filler
Technical data:
- coil: 12 V DC, flat connectors (2)
- max. pressure of safety valve (PRV): 2.7 Mpa (27 bar)
- PRV flow: 21.1 Nm3/min
- PRD flow: 2.0 Nm3/min
- refueling cut-off: 80%
Offered multivalve H 220-225 mm for internal toroidal tank. 30 degrees can be a replacement for:
- Tomasetto AT0202
- Landi Renzo
-OMB
- BRC MV Europa
Elpigaz AT02 SPRINT multivalve 220-225/30 tor. vertical
37.18€
Tax included
30,23 €
Net
We send it tomorrow.
EKX220W/BWES
Approval no.: E8 67R01 3018/16
Multivalve type: internal toroidal 30 degrees standard (d 6 mm)
Model: ELPIGAZ AT02 SPRINT
Height [H]: 220-225 mm
Application to internal toroidal tanks. 30 degrees with MVA flange for 6 screws:
- height [H]: 220-225 mm
- diameter [D]: 565-720 mm
Gas input (refueling): M12x1.0 mm, cable - d 8 mm
Gas outlet (to the reducer): M10x1.0 mm, cable - d 6 mm
Assembly: without gas filler
Technical data:
- coil: 12 V DC, flat connectors (2)
- max. pressure of safety valve (PRV): 2.7 Mpa (27 bar)
- PRV flow: 21.1 Nm3/min
- PRD flow: 2.0 Nm3/min
- refueling cut-off: 80%
Offered multivalve H 220-225 mm for internal toroidal tank. 30 degrees can be a replacement for:
- Tomasetto AT0202
- Landi Renzo
-OMB
- BRC MV Europa
The ELPIGAZ AT02 SPRINT multivalve (MVA) is designed for installation in internal toroidal tanks at an angle of 30 degrees and connected to the reducer - LPG evaporator with a 6 mm pipe. Recommended in LPG installations for vehicles with a power of up to 200 HP.
It contains such tank equipment as:
- valve limiting tank filling to 80%,
- automatic shut-off valve of the tank (electrovalve) with a valve limiting gas outflow,
- overpressure safety valve (PRV),
- thermal safety valve (PRD),
- socket for gas quantity indicator,
- manual shut-off valve.
The multivalve approved in accordance with UNECE regulation 67R01 is adapted to work with toroidal tanks with an MVA flange with an inclination angle of 30 degrees, according to the list in accordance with the approval granted for the tank in which it is installed.
The ELPIGAZ AT02 SPRINT multivalve can work with:
- ELPIGAZ reserve sensors (AE 81051R, AER 951R, AER 930R),
- with ELPIGAZ full indication sensors: nine-threshold (AE 81050R), resistive 0-90 ohm (AE81090R), contactless (RS001),
- with full indication and reserve sensors from AEB,
- with full indication and reserve sensors from other companies compatible with Tomasetto multi-valves.
All Tomasetto multi-valves are manufactured using high-tech processes and are 100% calibrated and tested.
The offered product includes:
- 220 / 30° multivalve for internal toroidal tanks,
- cable (harness) for connection with the solenoid valve coil,
- assembly bag (M5 screws, barrels, barrel clamps).
The set does not include:
- multivalve covers (housing),
- gas filler.
